5-channel class D compact amplifier with DSP

High efficient 5-channel class D amplifier with built-in 7-channel DSP

5-channel amplifier with high efficient class D circuit, integrated DSP and compact dimensions

• Compact sized 5-channel amplifier with DSP
• 7-channel DSP
• Class D technology
• 1 ohm stable (subwoofer channel)
• Parametric equalizer for each channel (10 bands/channel)
• Time alignment (0-8 ms / 0-272 cm / 0-107”) for each channel
• Adjustable crossover (HPF / LPF / BPF from 20 Hz to 20 kHz)
• Solid heatsink with engraved Ground Zero lettering
• High-level input with auto-on function
• Model Compact class D amplifier with DSP Channels 5+7 DSP Output Power (@ 4Ω) 4x 75 + 190 Watts RMS Output Power (@ 2Ω) 4x 125 + 320 Watts RMS Output Power (@ 1Ω) (subwoofer channel) 500 Watts RMS max. Output Power (CEA-2006A / 10%THD+N) 1200 Watts Frequency Response 20 Hz – 20 kHz HPF / LPF / BPF DSP Bass Boost / Phase switch DSP High level input / Auto-on ● / ● Remote ● BIAS Setting ○ Linkmode ○ Dimensions (W x L x H) 135 x 322 x 52 mm / 5.31″ x 12.68″ x 2.05″
