Class D micro amplifer

4-channel amplifier with small dimensions, integrated active crossover and auto-on function



Micro 4-channel amplifier

SMD components

Class D technology

Active crossover

2 ohms stable in stereo mode

Bridgeable for subwoofer use

ISO harness available separately



Model

Compact class D amplifier



Channels

4



Output Power (@ 4Ω)

4x 60 Watts RMS



Output Power (@ 2Ω)

4x 80 Watts RMS



max. Power (bridged) (@ 4Ω)

2x 160 Watts RMS



max. Ausgangsleistung (CEA-2006A / 10%THD+N)

2x 200 Watts



Frequency Response

10 Hz – 35 kHz



HPF / LPF / BPF

● / ● / ○



Bass Boost / Phase Shift

○ / ○



High-Level Input / Auto-on

● / ●



Remote

○



BIAS Setting

○



Linkmode

○



Dimensions (W x L x H)

82 x 151 x 40 mm / 3.23" x 5.94" x 1.57"
